FIELD OPERATION
4-56
3.3 Returns capacity bargraph M -- Figure 91
The performance bargraphs B are replaced by a re-
turns capacity bargraph M when
is pressed
for:
S Less than 3 seconds: The returns are dis-
played for 5 seconds. After that, the perform-
ance bargraphs are again displayed.
S More than 3 seconds: The returns are dis-
played until the performance bargraphs are se-
lected again by pushing
.
3.4 Threshing drum speed C -- Figure 92
This counter shows the current drum speed which can
be changed with the drum speed rocker switch.
54772
52693
91
92
