COPYRIGHT
©
2002 CANON INC. 2000 CANON iR1600/iR2000 REV.1 JAN. 2002
6-1
CHAPTER 6 PICKUP/FEDING SYSTEM
1 Outline
1.1 Specifications and Constructions
This chapter explains the pickup mechanism using the 1-cassette (built into the machine)
type. In the case of the 2-cassette type, refer to “Cassette Unit” in Chapter 9, as it will basi-
cally be a configuration based on the 1-cassette type to which a 1-cassette unit (accessory) is
installed.
The pickup/feeding system has the following functions and uses the following methods:
Item Description
Paper feed reference Center
Paper stack
Multifeeder 10 mm in height
Tray AB: Plain paper, recycled paper, colored paper
100 sheets if A4R, A4, B5, B5R, A5, A5R (80 g/m
2
)
50 sheets if A3, B4 (80 g/m
2
)
50 sheets if transparency, thick paper (90 to 128 g/m
2
)
10 sheets if envelope
Inch: Plain paper, recycled paper, colored paper
100 sheets if LTR, LTRR, STMT, STMTR (80 g/m
2
)
50 sheets if transparency, thick paper (90 to 128 g/m
2
)
10 sheets if envelope
50 sheets if 11x17 (279.4x431.8 mm), LGL
Cassette 25 mm in depth (250 sheets max. of 80 g/m
2
)
Paper size setting Cassette: by user
Manual feed tray: by user
Related user mode Paper size settings for manual feed tray
T06-101-01
To Next Page
