CHAPTER 13 TROUBLESHOOTING
COPYRIGHT © 2002 CANON INC. 2000 CANON iR1600/iR2000 REV.1 JAN. 2002
13-54
4 Arrangement and Functions of Electrical Parts
4.1 Outline
4.1.1 Outline
This section provides a diagram showing the arrangement of the machine’s and its acces-
sories’ electrical parts together with a listing.
The machine comes in two types: 1-cassette type and 2-cassette type. The 2-cassette type
is configured based on the 1-cassette type with the addition of a 1-cassette unit.
This section uses the 1-cassette type for discussions; for the 2-cassette type, see addition-
ally the discussions for the 1-cassette unit.
4.1.2 Checking the Sensors
The photointerrupters may be checked using ‘SENSOR’ under ‘TEST MODE’ in service
mode (6-3: SENSOR). (For specific instructions, see 5.5.7 of Chapter 13.)

Canon IR1600 Specifications

General

Print Technology	Laser
Type	Monochrome
Maximum Print Resolution	600 x 600 dpi
Print Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Standard Paper Capacity	250 sheets
Maximum Paper Size	A4
Functions	Print, Copy, Scan
Print Speed	16 ppm
Copy Speed	16 cpm
Scan Resolution	600 x 600 dpi
Operating System Compatibility	Windows
Interface	USB 2.0
