CHAPTER 13 TROUBLESHOOTING
COPYRIGHT © 2002 CANON INC. 2000 CANON iR1600/iR2000 REV.1 JAN. 2002
13-37
3.4 Troubleshooting Malfunctions
3.4.1 AC power is absent.
Initial checks
1) Is the power plug connected to the power outlet?
2) Is the rated AC voltage present at the power outlet?
3) Does the power switch operate normally?
Power supply PCB
4) IS the fuse (F1) on the power supply blown?
YES: Remove the cause, and replace the power supply PCB.
Wring, Connector
5) Is the wiring (continuity) and connection (connector contact) of the
wiring of the connectors (CN1, CN2, CN3) on the power supply
PCB normal?
NO: Correct the connection. If the flexible cable or the harness has a
scratch, replace it.
YES: Replace the power supply PCB.

Canon IR1600 Specifications

General

Print Technology	Laser
Type	Monochrome
Maximum Print Resolution	600 x 600 dpi
Print Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Standard Paper Capacity	250 sheets
Maximum Paper Size	A4
Functions	Print, Copy, Scan
Print Speed	16 ppm
Copy Speed	16 cpm
Scan Resolution	600 x 600 dpi
Operating System Compatibility	Windows
Interface	USB 2.0
