CHAPTER 13 TROUBLESHOOTING
COPYRIGHT © 2002 CANON INC. 2000 CANON iR1600/iR2000 REV.1 JAN. 2002
13-95
5.5.2 Test Mode Menu
To start test mode, press the User Mode key and then the # key; select ‘SERVICE
MODE’, and select ‘TEST MODE’ using the cursor key
/ , and press the OK key.
To end test mode, press the Stop key and then the Clear key.
*Not used.
F13-505-01
1 : D-RAM 13312K
1 : D-RAM 13312K
1-3 : IRAM TEST
OPT MEM
******
*
******
*
TEST MODE [1] - [6], [9]
E116 : EC-20-01
1 : D-RAM
[1] - - - [4]
*3 : PRINT
3-0 : AMI PATERN
*3 : PRINT
3-1 : WHITE
3 : PRINT
3-2 : BLACK
*3 : PRINT
3-3 : STRIPES
*3 : PRINT
3-4 : CHECKERS
*3 : PRINT
3-5 : CHECKERS-2
3 : PRINT
3-6 : ENDURANCE
*3 : PRINT
3-7 : BLACK/WHITE
*3 : PRINT
3-8 : BIAS
*3 : PRINT
3-9 : CHECKERS-3
*3 : PRINT
3- : PRINTING AREA
*3 : PRINT
3-# : CRG TEST
3 : PRINT
[0] - - - [9] , [ ], [#]
2 : CCD TEST
[1] - - - [8]
