CHAPTER 13 TROUBLESHOOTING
COPYRIGHT © 2002 CANON INC. 2000 CANON iR1600/iR2000 REV.1 JAN. 2002
13-44
3.4.10 The ‘Add Toner’ message fails to go OFF.
Developing assembly
1) Is the leaf spring of the contacts between the developing assembly
and the machine soiled with toner or the like?
YES: Clean the contacts. If the leaf spring has a scratch or deforma-
tion, replace it.
DC controller PCB
2) Is the leaf spring of the high-voltage contact of the DC controller
PCB deformed?
NO: Correct the fault. If the leaf spring has a scratch or deformation,
replace it.
Developing assembly
3) Try replacing the developing assembly. Is the fault corrected?
YES: Replace it.
NO: Replace the DC controller PCB.

Canon IR1600 Specifications

General

Print Technology	Laser
Type	Monochrome
Maximum Print Resolution	600 x 600 dpi
Print Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Standard Paper Capacity	250 sheets
Maximum Paper Size	A4
Functions	Print, Copy, Scan
Print Speed	16 ppm
Copy Speed	16 cpm
Scan Resolution	600 x 600 dpi
Operating System Compatibility	Windows
Interface	USB 2.0
