Canon IR1600 User Manual

CHAPTER 9 CASSETTE UNIT
COPYRIGHT © 2002 CANON INC. 2000 CANON iR1600/iR2000 REV.1 JAN. 2002
9-8
3 Detecting Jams
3.1 Outline
The re-try sensor (PS152) mounted to the cassette unit is used to monitor the movement
of paper, and the cassette paper sensor (PS151) is mounted to detect the presence/absence of
paper inside the cassette.
The presence/absence of paper is checked at such times as programmed in the CPU of the
cassette unit controller PCB; when a jam is detected, the CPU will immediately turn off the
main motor (M101) and pickup motor (M104) for the host and indicate the Jam message on
the control panel.
3.2 Sequence of Jam Detection
3.1.1 Delay Jam
See 4.2.1 of Chapter 6.
3.1.2 Stationary Jam
See 4.2.2 of Chapter 6.
3.1.3 Jam History
Se 4.2.4 of Chapter 6.

Canon IR1600 Specifications

General

Print Technology	Laser
Type	Monochrome
Maximum Print Resolution	600 x 600 dpi
Print Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Standard Paper Capacity	250 sheets
Maximum Paper Size	A4
Functions	Print, Copy, Scan
Print Speed	16 ppm
Copy Speed	16 cpm
Scan Resolution	600 x 600 dpi
Operating System Compatibility	Windows
Interface	USB 2.0
