CHAPTER 13 TROUBLESHOOTING
COPYRIGHT
©
2002 CANON INC. 2000 CANON iR1600/iR2000 REV.1 JAN. 2002
13-52
3.5.5 Feeding Fault (double feeding)
Paper
1) Is there more paper than allowed in the cassette (250 sheets)?
YES: Advise the user not to put more paper than allowed in the cassette.
Paper
2) Is the paper curled or wavy?
YES: Replace the paper. Advise the user on the correct method of storing
paper.
Machine state
3) Does the fault occur when the cassette is used as the source of pa-
per?
NO: Go to step 5.
Separation claw, Toque limiter
4) Is the separation claw of the cassette deformed?
YES: Correct the fault. If the fault cannot be corrected, replace the sepa-
ration roller.
NO: Replace the torque limiter.
Multifeeder tray
5) Is the manual feed separation pad worn?
YES: Replace the separation pad.
NO: Replace the separation pad pressure spring.
To Next Page
