CHAPTER 13 TROUBLESHOOTING
COPYRIGHT © 2002 CANON INC. 2000 CANON iR1600/iR2000 REV.1 JAN. 2002
13-83
5.4.4 Setting Original Read Functions (#6 SCANNER)
Item
1. Bit SW
2. SLICE
3. GAMMA
4. Numeric
5. LUT 1 fno
6. LUT 2 adj
7. CCD
8. MODEL
Description
Do not change. A change to the setting can adversely affect the read im-
age quality.
Some settings may be changed.
Used to turn on/off the original detection function.
#6 SCANNER-7
No.
0 to 17
18
19
20
21
22
23
24
25
26 to 28
29
30
31
32
34
Function
Do not change.
CS read start adjustment (for ADF read)
shading position adjustment
CS wobble correction distance (for ADF read)
main scanning direction image read start position ad-
justment (for book read)
main scanning direction image read start position ad-
justment (for ADF read)
sub scanning direction image read start position adjust-
ment (for book read)
sub scanning direction read start position adjustment
(for ADF read)
sub scanning direction image read end position correc-
tion (for copy)
Do not change.
main scanning direction image read ratio correction
(for book read)
main scanning direction image read ratio correction
(for ADF reading)
sub scanning direction image read ratio correction (for
book read)
sub scanning direction image read ratio correction (for
ADF read)
feed motor speed adjustment (for ADF read)
Range Unit
-
0 to 9999
unit : 0.1mm
0 to 9999
unit : 0.1mm
0 to 9999
unit : 0.1mm
0 to 9999
unit : 0.04mm
0 to 9999
unit : 0.04mm
0 to 9999
unit : 0.1mm
0 to 9999
unit : 0.1mm
0 to 9999
unit : 0.1mm
-
0 to 9999
unit : 0.1%
0 to 9999
unit : 0.1%
0 to 9999
unit : 0.1%
0 to 9999
unit : 0.1%
0 to 9999
unit : 0.1%
Default
-
470
90
40
128
128
145
235
52
-
16
16
16
16
50
