CHAPTER 13 TROUBLESHOOTING
COPYRIGHT © 2002 CANON INC. 2000 CANON iR1600/iR2000 REV.1 JAN. 2002
13-50
3.5.3 Transfer/Feeding Assembly
Paper
1) Try paper of a recommended type. Is the fault corrected?
YES: Advise the user to use recommended paper.
Paper
2) Is the paper curled or wavy?
YES: Replace the paper. Advise the user on the correct method of storing
paper.
Feeding assembly
3) Is there foreign matter/burrs in the feeding assembly?
YES: Remove it. Or, correct the fault.
Sensor
4) Is there paper over any of the sensors used to detect a jam? Or, are
the flag and the wiring of the sensor normal?
• retry sensor (PS152)
• registration paper sensor (PS101)
• delivery sensor (PS103)
YES: Remove it. Or, correct the fault. If the fault cannot be corrected,
replace the sensor.
Registration clutch (CL101)
5) Check the wiring from the connector J106 on the DC controller
PCB to the registration clutch (CL101). Is it normal?
NO: Correct the connection of the connectors.
Registration clutch
6) Try replacing the registration clutch. Is the problem corrected?
YES: End.
NO: Replace the DC controller PCB.
