CHAPTER 13 TROUBLESHOOTING
COPYRIGHT
©
2002 CANON INC. 2000 CANON iR1600/iR2000 REV.1 JAN. 2002
13-65
4.8.1 Image Processor PCB
F13-408-01
JP201: jumper wire for the battery (BAT1) used to back up the memory for control data
(user data, service data).
BAT1: battery used to back up control data (service mode data, user mode data).
J204
BAT1
JP201
J271
J216
J203
J204
J221
J264
J209
J211
J212
J263
J208
J206
JP201
