CHAPTER 8 EXTERNALS AND AUXILIARY CONTROL SYSTEM
COPYRIGHT
©
2002 CANON INC. 2000 CANON iR1600/iR2000 REV.1 JAN. 2002
8-2
2 Power supply
2.1 Power Supply
2.1.1 Outline
The machine’s DC power is generated by the AC power received by the power supply
PCB. The generated DC power is converted into a full-time ON system (linked to the power
switch) and a remote ON/OFF system (linked to control signals), and is supplied to each
load.
The output of the power supply PCB is controlled by the power switch (SW101) or sig-
nals from the printer board.
The names and functions of the parts associated with the power supply are as follows:
Name
Power supply PCB
Power switch
(SW101)
Cover switch
(DORSW1, DORSW2)
Description
generates DC power from AC power
supplies AC power to the power supply PCB
detects state (open/closed) of front cover and left cover
cuts 24VR2 power to main motor
T08-201-01
