Canon IR1600 - Service Mode; Outline

CHAPTER 13 TROUBLESHOOTING
COPYRIGHT © 2002 CANON INC. 2000 CANON iR1600/iR2000 REV.1 JAN. 2002
13-70
5 Service Mode
5.1 Outline
The items that follow may be checked/set using the machine’s service mode, which is de-
signed the way the service mode used in fax machines is designed in terms of contents and
operation. The machine’s service mode consists of the following 13 blocks.
As many as 11 items (#1 through #14) are offered, including test mode (TEST MODE).
#1 SSSW : service soft switch
Use it to make settings related to counter functions.
#2 MENU : Not used.
#3 NUMERICParam : Use it to select count types.
#4A SPECIAL : Not used.
#4B NCU : Not used.
#4C ISDN : Not used.
#5 TYPE : country setting
Use it to make collective settings realted to user data and service mode (#1 SSSW, #3 Nu-
meric Param.) to suit the country of installation indicated on the display.
#6 SCANNER : (partly available in service mode)
Do not use it except for ‘7: CCD’ at time of adjusting image position; a change to the set-
ting can adversely affect the read image quality.
#7 PRINTER : printer settings
Use it to make registration/settings related to basic printer functions.
#8 PDL : Do not use.
#9 COUNTER : counter indication
Use it to check estimates for maintenance/parts replacement.
#10 REPORT : report output
Use it to generate reports on various service data.
#11 DOWNROAD : download
Use it to download firmware to the ROM of a PCB in question.
