CHAPTER 13 TROUBLESHOOTING
COPYRIGHT © 2002 CANON INC. 2000 CANON iR1600/iR2000 REV.1 JAN. 2002
13-51
3.5.4 Fixing/Delivery Assembly
Machine state
1) Is the machine equipped with an inner 2-way tray? Is the jam in
the delivery tray A (No. 2 delivery slot)?
NO: Go to step 3.
2-way solenoid, wiring
2) Are the 2-way solenoid and the wiring to the solenoid normal?
NO: Correct the fault.
Sensor
3) Is there paper over any of the following sensors? Also, are the flag
and wiring for the sensor normal?
• retry- sensor (PS152)
• registration paper sensor (PS101)
• delivery sensor (P103)
• No. 2 delivery sensors (PS201; for inner 2-way tray)
YES: Remove the paper. Or, correct the fault.
Fixing assembly
4) Try replacing the fixing assembly. Is the problem corrected?
YES: End.
NO: Replace the DC controller PCB.

Canon IR1600 Specifications

General

Print Technology	Laser
Type	Monochrome
Maximum Print Resolution	600 x 600 dpi
Print Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Standard Paper Capacity	250 sheets
Maximum Paper Size	A4
Functions	Print, Copy, Scan
Print Speed	16 ppm
Copy Speed	16 cpm
Scan Resolution	600 x 600 dpi
Operating System Compatibility	Windows
Interface	USB 2.0
