Canon IR1600 User Manual

CHAPTER 9 CASSETTE UNIT
COPYRIGHT © 2002 CANON INC. 2000 CANON iR1600/iR2000 REV.1 JAN. 2002
9-1
1 Outline
1.1 Outline
The machine may be equipped with a 1-cassette, 3-cassette (for iR1600), or 2-cassette
(for iR2000) feeding unit.
1.2 Specifications and Construction
Item
Pickup
Paper stack
1-cassette unit
2-cassette unit
3-cassette unit
Paper size setting
Paper type
Paper size
Pickup control
1-cassette unit
2-cassette unit
3-cassette unit
Drive source
1-cassette unit
2-cassette unit
3-cassette unit
Description
Retard method
250 sheets (80 g/m
2
)
250 sheets x 2 (80/m
2
)
250 cassette x 3 (80 g/m
2
)
By user
Plain, recycled paper (60 to 90 g/m
2
)
A5/STMT to A3/11 x 17 (279mm x 432mm)
1-cassette unit controller PCB
2/3-cassette unit controller PCB
2/3-cassette unit controller PCB
From main motor of host
From pickup motor of cassette unit
For cassette 1, from main motor of host; for 2/3 cassette, from cas-
sette pickup motor mounted to 2nd cassette
T09-102-01

Canon IR1600 Specifications

General

Print Technology	Laser
Type	Monochrome
Maximum Print Resolution	600 x 600 dpi
Print Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Standard Paper Capacity	250 sheets
Maximum Paper Size	A4
Functions	Print, Copy, Scan
Print Speed	16 ppm
Copy Speed	16 cpm
Scan Resolution	600 x 600 dpi
Operating System Compatibility	Windows
Interface	USB 2.0
