CHAPTER 12 MAINTENANCE AND INSPECTION
COPYRIGHT
©
2002 CANON INC. 2000 CANON iR1600/iR2000 REV.1 JAN. 2002
12-2
2 Guide to Durables
Some durables of the machine require replacement once or more over the life of the prod-
uct because of wear or damage. Replace them when they fail.
2.1 Checking the Timing of Replacement
Check the timing of replacement in service mode as follows:
1) Start service mode, and make the following selections: #9 COUNTER>DRBL-1; then,
press the OK key.
2) Select the appropriate item using the cursor key, and press the OK key to check the
counter reading.
2.2 Copier
As of September 2001
No. Parts name Parts No. Q’ty Life Remarks
1 Fixing roller FB5-8132 1 150,000 copies Actual copies made.
2 Pressure roller FB6-1549 1 150,000 copies Actual copies made.
3 Fixing roller bushing FB6-1548 2 150,000 copies Actual copies made.
4 Separation claw FB5-8143 5 150,000 copies Actual copies made.
5 Develping assembly FG6-8413 1 150,000 copies Actual copies made.
6 Transfer charging roller FB5-8019 1 150,000 copies Actual copies made.
7 Multifeeder separation pad FB5-8028 1 50,000 copies Actual copies made.
8 Multifeeder pickup roller FF6-1671 1 50,000 copies Actual copies made.
T12-202-01
2.3 Cassette Unit
The cassette unit does not have parts that are referred to as durables.
2.4 Inner 2-Way Tray
The inner 2-way tray does not have parts referred to as durables.
