CHAPTER 2 BASIC OPERATION
COPYRIGHT
©
2002 CANON INC. 2000 CANON iR1600/iR2000 REV.1 JAN. 2002
2-5
1.2.3 Power Supply PCB
The following are generated from the common AC power for supply to various loads: full-
time ON system, (DC +12VS, DC +5VS, DC +3VS1, DC +3VS2), remote ON/OFF system
(DC +24VR1, DC +24VR2, DC +5VR, DC +3VR).
1.2.4 Analog Processor PCB
The analog data read of an original by the CS unit is converted into digital data for output
to the image processor PCB.
