CHAPTER 13 TROUBLESHOOTING
COPYRIGHT
©
2002 CANON INC. 2000 CANON iR1600/iR2000 REV.1 JAN. 2002
13-40
3.4.4 Pickup operation fails. (multifeeder tray)
Main motor (M101)
1) Is ‘E010’ (fault in main motor) indicated?
YES: See the descriptions for ‘E010’ in 6.2.1.
User mode setting
2) Is multifeeder tray selected in the control panel?
NO: Select the multifeeder tray.
Paper
3) Is paper placed correctly in the multifeeder tray?
NO: Place the paper correctly.
Holding plate lift mechanism
4) Doest the holding plate move up in keeping with pickup timing?
NO: Check the spring used to push up the holding plate.
Pickup roller
5) Is there wear or cracking in the surface of the manual feed pickup
roller?
YES: Replace the pickup roller.
Pickup drive assembly gear
6) Is there damage/foreign matter on the gear of the pickup roller
drive assembly?
YES: If damage is found, replace the gear. If foreign matter is found, re-
move it.
Multifeeder pickup solenoid (SL101)
7) Is the connection between the connector (J904) of the multifeeder
pickup solenoid and the connector (J106) on the DC controller PCB
normal?
NO: Correct the connection.
Multifeeder pickup solenoid, DC controller PCB
8) Does the multifeeder pickup solenoid operating normally?
YES: Replace the DC controller PCB.
NO: Replace the multifeeder solenoid.
To Next Page
