CHAPTER 13 TROUBLESHOOTING
COPYRIGHT © 2002 CANON INC. 2000 CANON iR1600/iR2000 REV.1 JAN. 2002
13-42
3.4.6 The vertical path roller fails to rotate.
Main motor (M101)
1) Is ‘E010’ (fault in main motor) indicated?
YES: See the descriptions for ‘E010’ in 6.2.1.
Machine state
2) Is the pickup roller rotating?
YES: Check the vertical path roller drive assembly for damage/foreign
matter.
If damage is found, replace the gear. If foreign matter is found, re-
move it.
NO: See “Pickup operation fails” for the source of paper used.
3.4.7 The registration roller fails to rotate.
Connector
1) Is the connection between the connector (J905) of the registration
clutch and the connector (J106) on the DC controller PCB normal?
NO: Correct the connection.
Registration clutch
2) Try replacing the registration clutch. Is the problem corrected?
YES: Replace the registration clutch.
NO: Replace the DC controller PCB.
