Canon IR1600 User Manual

COPYRIGHT © 2002 CANON INC. 2001 2001 2001 2001 CANON Printer Board-N1/iN-E5 REV.0 JAN. 2002
iii
CONTENTS
Contents
CHAPTER 1 INTRODUCTION
1 Outline ................................................ 1-1
1.1 Outline ....................................... 1-1
2 Specifications ..................................... 1-2
2.1 Printer Board-N1 ....................... 1-2
2.2 Ethernet Network Interface
Adapter iN-E5 ........................... 1-2
2.3 Hard Disk HD-65 ...................... 1-2
3 Operation ............................................ 1-3
3.1 Making Network Settings ......... 1-3
3.2 Making Printer Settings ............ 1-3
1 Construction ....................................... 2-1
1.1 Outline ....................................... 2-1
1.2 Functional Blocks of the
Printer Board ............................. 2-1
1.3 Upgrading .................................. 2-4
CHAPTER 2 OPERATION
1 Disassembly and Assembly ............... 3-1
1.1 Removing the Hard Disk........... 3-2
1.2 Removing the Network
Interface Board .......................... 3-3
1.3 Removing the Printer Board ..... 3-4
CHAPTER 3 DISASSEMBLY/ASSEMBLY
1 Printer Board-N1 Installation
Procedure ............................................ 4-1
1.1 Unpacking and Checking the
Contents ..................................... 4-1
1.2 Installing the Printer Board-N1 4-2
1.3 Making Checks After
Installation ................................. 4-5
1.4 Unpacking the Hard Disk HD-65
and Checking the Contents ....... 4-6
1.5 Installing the Hard Disk HD-65
................................................... 4-7
1.6 Installing the Expansion RAM/
Flash ROM Module FR-65 ..... 4-11
1.6.1 Preparing for the Work ..... 4-12
1.6.2 Installation......................... 4-12
1.6.3 Making Checks After
Installation......................... 4-14
2 Ethernet Network Interface Adapter
iN-E5 Installation Procedure ........... 4-15
2.1 Unpacking and Checking the
Contents ................................... 4-15
2.2 Installation ............................... 4-16
2.3 Making Checks After
Installation ............................... 4-20
CHAPTER 4 INSTALLATION

Canon IR1600 Specifications

General

Print Technology	Laser
Type	Monochrome
Maximum Print Resolution	600 x 600 dpi
Print Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Standard Paper Capacity	250 sheets
Maximum Paper Size	A4
Functions	Print, Copy, Scan
Print Speed	16 ppm
Copy Speed	16 cpm
Scan Resolution	600 x 600 dpi
Operating System Compatibility	Windows
Interface	USB 2.0
