CHAPTER 13 TROUBLESHOOTING
COPYRIGHT © 2002 CANON INC. 2000 CANON iR1600/iR2000 REV.1 JAN. 2002
13-31
3.3.15 The copy has displaced registration. (leading edge extremely
excessive margin).
3.3.16 The copy has displaced registration. (leading edge, excessive margin)
3.3.17 The copy has displaced registration. (leading edge, no margin)
Original
1) Is the original placed correctly?
NO: Place the original correctly.
ADF
2) Is an ADF used?
YES: Adjust the leading edge for the ADF as instructed in the ADF Ser-
vice Manual.
Pickup roller, Feed roller, Separation roller
3) Try replacing the pickup, feeding, and separation roller of the
source of paper (cassette). Is the problem corrected?
YES: Replace the roller in question.
Image position
4) Try image position adjustment in service mode. Is the fault cor-
rected? (See 2.1.2 of Chapter 13.)
YES: End.
Registration clutch, DC controller PCB
5) Is the registration clutch operating normally?
YES: Replace the DC controller PCB.
NO: Replace the registration clutch.

Canon IR1600 Specifications

General

Print Technology	Laser
Type	Monochrome
Maximum Print Resolution	600 x 600 dpi
Print Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Standard Paper Capacity	250 sheets
Maximum Paper Size	A4
Functions	Print, Copy, Scan
Print Speed	16 ppm
Copy Speed	16 cpm
Scan Resolution	600 x 600 dpi
Operating System Compatibility	Windows
Interface	USB 2.0
