Canon IR1600 User Manual

CHAPTER 2 BASIC OPERATION
COPYRIGHT © 2002 CANON INC. 2000 CANON iR1600/iR2000 REV.1 JAN. 2002
2-11
1.4.3 Basic Sequence of Operation (printing)
F02-104-02
Start key ON or print signal input
Scanner motor
(M102)
Cassette pickup
solenoid(SL151)
Re-try sensor
(PS152)
Registration paper
sensor(PS101)
Registration clutch
(CL102)
Delivery sensor
(PS103)
Primary charging
(AC)
Primary charging
(DC)
CS LED
Developing bias
(DC)
Developing bias
(AC)
Laser diode
Transfer high voltage
Fixing heater(H101)
CS unit HP sensor
(PS113)
Reader motor
(M103)
Main motor
(M101)
STBY
INTR PRINT LSTR
TOP * signal
STBY
*1
*2
ForwardReverse
Cleaning bias
*1: varies according to density setting. If PDL output, the copying is constant
*2: ATVC control.

Canon IR1600 Specifications

General

Print Technology	Laser
Type	Monochrome
Maximum Print Resolution	600 x 600 dpi
Print Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Standard Paper Capacity	250 sheets
Maximum Paper Size	A4
Functions	Print, Copy, Scan
Print Speed	16 ppm
Copy Speed	16 cpm
Scan Resolution	600 x 600 dpi
Operating System Compatibility	Windows
Interface	USB 2.0
