CHAPTER 13 TROUBLESHOOTING
COPYRIGHT
©
2002 CANON INC. 2000 CANON iR1600/iR2000 REV.1 JAN. 2002
13-41
3.4.5 Pickup operation fails. (cassette unit)
Main motor (M101)
1) Is ‘E010’ (main motor fault) indicated?
YES: See the descriptions for ‘E010’ in 6.2.1.
Machine state
2). Is the pickup roller rotating?
NO: Go to step 5.
Paper
3) Is the cassette fitted correctly.
NO: Fit the cassette correctly.
Pickup roller
4) Is there wear, scratches, or cracks in the surface of the pickup
roller?
YES: Replace the pickup roller.
Pickup drive assembly gear
5) Is there damage/foreign matter in the pickup roller drive assembly?
YES: If damage is found, replace the damaged gear. If foreign matter is
found, remove it.
Cassette pickup solenoid (SL151)
6) Is the connection between the connector of the cassette pickup sole-
noid and the connector of the cassette unit controller PCB normal?
NO: Connect the connectors correctly.
Cassette pickup solenoid
7) Does the cassette pickup solenoid operate normally?
NO: Replace the cassette pickup solenoid.
Pickup motor (M104; for 3rd/4th cassette)
8) Does the pickup motor operate normally?
YES: Replace the pickup motor.
NO: Replace the cassette pickup solenoid.
Cassette unit controller PCB/DC controller PCB
9) Try replacing the cassette unit controller PCB. Is the fault cor-
rected?
YES: Replace the cassette unit controller PCB.
NO: Replace the DC controller PCB.
To Next Page
