SINAMICS G130/G150
List Manual (LH2), 04/2014, A5E03263479A
205
2 Parameters
2.2 List of parameters
Description: Displays the trace signal for encoder diagnostics (double word).
The signal to be output is selected in p0496.
Dependency: Refer to: p0496, r0498, r0499
Description: Displays the trace signal for encoder diagnostics (double word).
The signal to be output is selected in p0496.
Index: [0] = Encoder 1
[1] = Encoder 2
[2] = Encoder 3
Dependency: Refer to: p0496, r0498, r0499
Description: Displays the trace signal for encoder diagnostics (low component).
The signal to be output is selected in p0496.
Dependency: Refer to: p0496, r0497, r0499
Description: Displays the trace signal for encoder diagnostics (low component).
The signal to be output is selected in p0496.
Index: [0] = Encoder 1
[1] = Encoder 2
[2] = Encoder 3
Dependency: Refer to: p0496, r0497, r0499
r0497 Encoder diagnostic signal double word / Enc diag DW
ENC Can be changed: - Calculated: - Access level: 4
Data type: Unsigned32 Dyn. index: - Func. diagram: -
P-Group: Encoder Units group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
- - -
r0497[0...2] CO: Encoder diagnostic signal double word / Enc diag DW
VECTOR_G Can be changed: - Calculated: - Access level: 4
Data type: Unsigned32 Dyn. index: - Func. diagram: -
P-Group: Encoder Units group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
- - -
r0498 Encoder diagnostic signal low word / Enc diag low word
ENC Can be changed: - Calculated: - Access level: 4
Data type: Integer16 Dyn. index: - Func. diagram: -
P-Group: Encoder Units group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
- - -
r0498[0...2] CO: Encoder diagnostic signal low word / Enc diag low word
VECTOR_G Can be changed: - Calculated: - Access level: 4
Data type: Integer16 Dyn. index: - Func. diagram: -
P-Group: Encoder Units group: - Unit selection: -
Not for motor type: - Scaling: - Expert list: 1
Min Max Factory setting
- - -
