SINAMICS G130/G150
List Manual (LH2), 04/2014, A5E03263479A
375
2 Parameters
2.2 List of parameters
Description: Sets the scaling for the compensation torque within the droop calculation.
Description: Sets the source for droop feedback.
With increasing torque, the speed setpoint is reduced (enabled using p1492), so that for mechanically coupled drives
a load equalization (load compensation) is obtained.
A load difference compensation is also possible, if p1486 is interconnected with the torque setpoint of the other drive.
Value: 0: Droop feedback not connected
1: Droop from torque setpoint
2: Droop from speed controller output
3: Droop from integral output speed controller
Dependency: Refer to: p1486, p1487, p1489, r1490, p1492
Caution: For active acceleration precontrol of the speed controller (refer to p1496), it is not recommended that p1488 is set to
1, as this could result in positive coupling effects. Instead of this, as source of the droop feedback, the output signal
of the speed controller should be used, which generally sets the load torque.
Description: Sets the scaling for the droop feedback
Dependency: Refer to: p1486, p1487, p1488, r1490, p1492
Note: Example:
A value of 0.05 means that for a torque equal to the rated motor torque, the rated motor speed is reduced by 5 %.
Description: Displays the output signal of the droop calculation. The droop feedback result is subtracted from the speed setpoint
when activated (p1492).
Dependency: Refer to: p1486, p1487, p1488, p1489, p1492
p1487[0...n] Droop compensation torque scaling / Droop M_comp scal
VECTOR_G (n/M) Can be changed: U, T Calculated: - Access level: 3
Data type: FloatingPoint32 Dyn. index: DDS, p0180 Func. diagram: 6030
P-Group: Closed-loop control Units group: - Unit selection: -
Not for motor type: REL Scaling: PERCENT Expert list: 1
Min Max Factory setting
-2000.0 [%] 2000.0 [%] 100.0 [%]
p1488[0...n] Droop input source / Droop input source
VECTOR_G (n/M) Can be changed: U, T Calculated: - Access level: 3
Data type: Integer16 Dyn. index: DDS, p0180 Func. diagram: 6030
P-Group: Closed-loop control Units group: - Unit selection: -
Not for motor type: REL Scaling: - Expert list: 1
Min Max Factory setting
0 3 0
p1489[0...n] Droop feedback scaling / Droop scal
VECTOR_G (n/M) Can be changed: U, T Calculated: - Access level: 3
Data type: FloatingPoint32 Dyn. index: DDS, p0180 Func. diagram: 6030
P-Group: Closed-loop control Units group: - Unit selection: -
Not for motor type: REL Scaling: - Expert list: 1
Min Max Factory setting
0.000 0.500 0.050
r1490 CO: Droop feedback speed reduction / Droop n_reduction
VECTOR_G (n/M) Can be changed: - Calculated: - Access level: 3
Data type: FloatingPoint32 Dyn. index: - Func. diagram: 6030
P-Group: Closed-loop control Units group: 3_1 Unit selection: p0505
Not for motor type: REL Scaling: p2000 Expert list: 1
Min Max Factory setting
- [rpm] - [rpm] - [rpm]
