Commands Listed in Alphabetical Order
Syntax
CH<x>:PRObe:U
NIts?
Related Commands
CH<x>:PROBEFunc:EXTUnits
Examples
CH4:PROBE:UNITS? might return :CH4:PROBE:UNITS "V", indicating that the
units of measure for the probe attached to Channel 4 are volts.
CH<x>:PROBECal? (Query Only)
This query-only command returns the probe calibration state for the selected
channel. The channel is specified by x. The value of x can range from 1 through
4. This command is equivalent to selecting Probe Cal from the Vertical menu.
Group
Vertical
Syntax
CH<x>:PROBECal?
Returns
This query will return one of the following:
FAIl signifies that the p robe calibration h as failed for the selected channel.
INIT signifies that the probe calibration has not yet been run for the selected
channel.
PASS signifies the probe calibration has passed for the select ed channel.
Examples
CH2:PROBECAl? might return :C H2:PROBECAL PASS indicating that the probe
calibration has passed for Channel 2.
CH<x>:PROBECOntrol
This command allows you to set or query the probe range.
Group
Vertical
Syntax
CH<x>:PROBECOntrol {AUTO|MANual}
CH<x>:PROBECOntrol?
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-125
