Commands Listed in Alphabetical Order
Examples
HORIZONTAL:DE
LAY:MODE O N
enables the time base trigger delay mode.
HORIZONTAL:DELAY:MODE? might return :HORIZONTAL :DELAY:MODE 1,
indicating th
at the time base trigger delay mode is currently enabled.
HORizontal[:MAIn]:DELay:POSition
This command sets or queries the time base position when Horizontal Delay Mode
is turned on. This command is equivalent to selecting Horizontal/Acquisition
Setup from the Horiz/Acq menu and then entering a Ref Point value.
Group
Horizontal
Syntax
HORizontal[:MAIn]:DELay:PO Sition <NR3>
HORizontal[:MAIn]:DELay:PO Sition?
Related Commands
HORizontal[:MAIn]:DELay:TIMe
Arguments
<NR3> is from 0 to ≈100 and is the percentage of the waveform that is displayed
left of the center graticule.
NOTE. The upper limit of the waveform position is slightly limited by a value that
is determined from the record length (upper limit = 100 - 1/record length).
Examples
HORIZONTAL:DELAY:POSITION 5E+1 sets the time base trigger delay position
to 50 percent.
HORIZONTAL:DELAY:POSITION? might return
:HORIZONTAL:MAIN:DELAY:POS ITION 5.0000E+01, indicating that the time
base trigger delay position is currently set to 50 percent.
HORizontal[:MAIn]:DELay:TIMe
This command sets or queries the time base trigger delay time. This command is
equivalent to selecting Position/Scale from the Horiz/Acq menu and choosing a
value for Horiz Delay.
Group
Horizontal
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-257
