Tektronix DPO70000 Series Programmer's Manual

Commands Listed in Alphabetical Order
<NR1>=0disabl
esthesavelogfile feature so that when the source waveform data
exceeds the limits set by the limit test, a log file is not saved; any other value
enables the save log file feature so that when the source wave form data exceeds
the limits set by the limit test, a log file is saved. For queries, a 0 is returned if the
save log file feature is off; a 1 is returned if the save log file feature is on.
Examples
LIMIT:LOG 1 enables the save log file feature so that when the so urce waveform
data exceeds the limits set by the limit test, a log file is saved.
LIMIT:LOG? might return :LIMIT:LOG 0, indicating that the save log file
feature is disabled and that a log file will not be saved when the source waveform
exceeds the limits of the limit test.
LIMit:SAVEWFM
This command sets or queries whether the source waveform is saved when the
source waveform data exceeds the test limits.
NOTE. The command works only if the LT Limit Test option is enabled.
Group
Limit Test
Syntax
LIMit:SAVEWFM {OFF|ON|<NR1>}
LIMit:SAVEWFM?
Arguments
OFF disables saving the source
waveform when it exceeds the test limits.
ON enables saving the source waveform when it exceeds the test limits.
<NR1> = 0 disables the save waveform feature so that when the source waveform
data exceeds the limits set by the limit test, the source wave form is not saved; any
other value enables the save
waveform feature so that when the source waveform
data exceeds the limits set by the limit test, the source waveform is saved. For
queries, a 0 is returned if the save waveform feature is off; a 1 is returned if the
save waveform feature is on.
Examples
LIMIT:SAVEWFM 1 enables the save waveform feature so that when the source
waveform data exceeds the limits set by the limit test, the source waveform
is saved.
LIMIT:SAVEWFM? might return :LIMIT:SAVEWFM 0, indicating that the save
waveform feature is disabled and that the source waveform will not be saved
when it exceeds the limits of the limit test.
2-272 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
