Command Groups
Command
Description
WFMOutpre:PT_Off?
Returns the tr
igger point relative to
DATA:START for the waveform
WFMOutpre:PT_ORder? Returns whether the source waveform is
DPO
WFMOutpre:WFId?
Returns a string describing the acquisition
parameters for the waveform
WFMOutpre:XINcr?
Returns the horizontal sampling interval
WFMOutpre:XUNit? Returns the horizontal units for the waveform
WFMOutpre:XZEro? Returns the (sub-sample) time between the
trigger s
ample and the occurrence of the
actual waveform trigger
WFMOutpre:YMUlt? Returns the vertical scale factor per digitizing
level for the waveform
WFMOutpre:YOFf? Returns the vertical offset in digitizing levels
for the w
aveform
WFMOut
pre:YUNit?
Return
s the vertical units for the waveform
WFMOu
tpre:YZEro?
Retur
ns the vertical offset for the waveform
WFMInpre:NR_FR
Sets o
r returns one frame, indicating
the number of frames in the transmitted
waveform record
WFMOutpre:NR_FR? Query-only command returns the number
of fr
ames for the DATa:SOUrce waveform
transmitted in response to a CURVe?query
Zoom C ommand Group
Zoom commands let you expand and position the waveform display horizontally
and vertically, without changing the time base or vertical settings.
Youcanspecifyuptofourzoomareas.Youcanalsospecifyazoomedwaveform
as a z oom source, which enables you to zoom in on a zoomed waveform.
Command
Description
ZOOm Resets the zoom transforms to default values
for all traces or live traces. Th
e ZOOm query
returns the current vertical and horizontal
positioning and scaling of the display
ZOOm:GRA ticule:SIZE Sets or returns the size of the zoom graticule
ZOOm:HORizontal:POSition Sets or queries the horizontal position around
which the zoom waveform is dis
played.
It is freely movable within the confines of
the acquired waveform (0% to 100%) and
measured from left to right o
f the acquired
waveform
2-72 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
