Tektronix DPO70000 Series Programmer's Manual

Commands Listed in Alphabetical Order
Arguments
<NR3> is the amo
unt, in horizontal divisions, by which the current source
waveform is allowed to deviate from the template waveform without exceeding
the limits set in the limit test. The range is 0 to 5 divisions.
Examples
LIMIT:TEMPLATE:TOLERANCE: HORIZONTAL 1.0 specifies that the current
waveform is close enough to the template waveform if it is within ±1.0 horizontal
division.
LIMIT:TEMPLATE:TOLERANCE: HORIZONTAL? might return
:LIMIT:TEMPLATE:TOLERANCE :HORIZONTAL 2.0, indicating that the current
waveform is close enough to the template waveform if it is within ±2.0 horizontal
divisions.
LIMit:TEMPlate:TOLerance:VERTical
This command sets or queries the amount, in units of vertical divisions, by which
the source waveform is varied vertically when creating the destination waveform.
NOTE. The command works only if the LT Limit Test op
tion is enabled.
Group
Limit Test
Syntax
LIMit:TEMPlate:TOLerance: VERTical <NR3>
LIMit:TEMPlate:TOLerance: VERTical?
Arguments
<NR3> is the amount, in vertical divisions, by which the current source waveform
is allowed to deviate from the template waveform without exceeding the limits set
in the limit test. The range is 0 to 5 divisions.
Examples
LIMIT:TEMPLATE:TOLERANCE: VERTICAL 1.0 specifies that the current
waveform is close enough to the template waveform if it is within ±1.0 vertical
division.
LIMIT:TEMPLATE:TOLERANCE: VERTICAL? might return
:LIMIT:TEMPLATE:TOLERANCE :VERTICAL 2.0, indicating that the
current waveform is close enough to the template waveform if it is within
±2.0 vertical divisions
.
LOCk
This command enables or disables all front panel buttons and knobs, including
the touch screen. There is no front panel equivalent.
2-278 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
