Tektronix DPO70000 Series Programmer's Manual

Commands Listed in Alphabetical Order
Arguments
<NR3> specifies
the left position of the histogram box in source waveform
coordinates.
<NR3> specifie
s the top position of the histogram box in source waveform
coordinates.
<NR3> speci
fies the right position of the histogram box in source waveform
coordinates.
<NR3> speci
fies the bottom position of the histogram box in source waveform
coordinates.
Examples
HISTOGRAM:BOX 1E-9, 0. 250, 2E-9, 0.500 defines the coordinates of the
histogram box in source waveform coordinates.
HISTOGRAM:BOX? might return :HISTOGRAM:BOX 1.0000E-09, 0.2500,
2.0000E-09, 0.5000
, which identifies the coordinates of the histogram box in
source waveform coordinates.
HIStogram:BOXPcnt
This command defines or queries the left, top, right, and bottom positions of
the histogram box, in percentage coordinates. The upper left has the value 0,0
and the lower right has the value 100, 100. Any value outside the range of 0
to 100 is clipped. This command is similar to the HIStogram:BOX command
except that this command uses percentage coordinates to define the boundaries
of the histogram box.
NOTE. This command implicitly clears the histogram count and statistics for the
histogram and histogram source data when HIStogram:STATE is turned on.
Group
Histogram
Syntax
HIStogram:BOXPcnt <NR2>, <NR2>, <NR2>, <NR2>
HIStogram:BOXPcnt?
Related Commands
HIStogram:BOX
Arguments
<NR2> specifies the left position of the histogram box in percentage coordinates.
Thedefaultvalueis30.0.
<NR2> specifies the top position of the histogram box in percentage coordinates.
Thedefaultvalueis25.1.
2-232 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
