Commands Listed in Alphabetical Order
LIMit:TEMPla
te:STORe (No Query Form)
This command (no query form) saves the specified source waveform to the
specified reference or file name.
NOTE. The co
mmand works only if the LT Limit Test option is enabled.
Group
Limit Test
Syntax
LIMit:TEMPlate:STORe <wfm>,{REF<x>| <file path>}
Arguments
<wfm> specifies the waveform that will be saved as the template. The source of the
waveform can be CH<x> (where x is 1 through 4 for four channel instruments),
MATH<x>, or Ref<x> (where x is 1 through 4).
REF<x> specifies a reference loca tion in which the template waveform will be
stored. The reference waveform specified by x, which can be 1 through 4.
<file p ath> specifies a fi le path where the template waveform will be stored.
This argument is a quoted string.
Examples
LIMIT:TEMPLATE:STORE CH3,REF1 creates a template reference waveform,
REF1, using Channel 3 as its source.
LIMIT:TEMPLATE:STORE CH1,"TEMPLATE. WFM" creates a template reference
waveform, template.wfm, using Channel 1 as the source.
LIMit:TEMPlate:TOLerance:HORizontal
This command s ets or queries the amount, in units of horizontal divisions, by
which the source waveform is varied horizontally when creating the destination
waveform.
NOTE. The command works only if the LT Limit Test option is enabled.
Group
Limit Test
Syntax
LIMit:TEMPlate:TOLerance:H ORizontal <NR3>
LIMit:TEMPlate:TOLerance:H ORizontal?
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-277
