Commands Listed in Alphabetical Order
Examples
MEASUREMENT:N
OISE HIGH
causes the noise measurement to be made at the
high level of the waveform.
MEASUREMENT:
NOISE?
might return :MEASUREMENT:NOISE LOW, indicating
that the noise measurement will be made at the low level of the waveform.
MEASUrement:REFLevel:ABSolute:HIGH
This command sets or queries the high reference level, and is the upper reference
level when MEASUrement:REFLevel:METHod is set to Absolute. This
command affects the results of rise and fall measurements and is e quivalent
to select
ing Reference Levels from the Measure menu, and then entering the
Absolute High Ref value.
NOTE. this command affects the associated reference level parameter
for all MEASurements:IMMed and the eight periodic measurements.
To change the parameter for individual measurements, use the
MEASUrement:MEAS<x>:REFLevel commands.
Group
Measurement
Syntax
MEASUrement:REFLevel:ABSol ute:HIGH <NR3>
MEASUrement:REFLevel:ABSol ute:HIGH?
Related Commands
MEASUrement:REFLevel:METHod, MEASUrement:IMMed:TYPe,
MEASUrement:MEAS<x>:TYPe
Arguments
<NR3> is the high reference level, in volts. The default is 0.0 V.
Examples
MEASUREMENT:REFLEVEL:ABSOL UTE:HIGH 1.71 sets the high refere nce level
to 1.71 V.
MEASUREMENT:REFLEVEL:ABSOL UTE:HIGH? might return
:MEASUREMENT:REFLEVEL:ABSO LUTE:HIGH 1.7100E+00,
indicating that the absolute high reference level is set to 1.71 V.
MEASUrement:REFLevel:ABSolute:LOW
This command sets or queries the low reference level, and is the lower reference
level when MEASUrement:REFLevel:METHod is set to Absolute. This
command affects the results of rise and fall measurements and is e quivalent
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-403
