Tektronix DPO70000 Series Programmer's Manual

Commands Listed in Alphabetical Order
MATH<x>:SPEC
Tral:LOCk
This command locks menus for two or more math waveforms together as a group.
The query form of this command returns an ON (1) or OFF (0), indicating whether
spectral loc
king is turned on. This command is equal to selecting Spectral Setup
from the Math menu, choosing the Control tab and then clicking the Time/Track
Frequency Domain Controls button associated with the math waveforms that
you want to lock.
Table 2-17: Math<x> Lock Combinations
Math1 Math2 Math3 Locked Mat
h Waveforms
Off Off Off
None
Off Off On
Math3 and Math4 locke d
Off On Off
Math2 and Math3 locke d
Off On On
Math2, Math3, and Math4 locked
On Off Off
Math1 and Math2 locke d
On Off On
Math1 and Math2 locked, Math3
and Ma
th4 locked
On On Off
Math1, Math2, and Math3 locked
On On On
Math1, Math2, Math3, and Math4
lock
ed
NOTE. Executing MATH4:SPECTral:LOCk via the GPIB interface has n o effect
since there is no Math5 to which it can be locked.
Group
Ma
th
Syntax
MATH<x>:SPECTral:LOCk {ON|OFF}
MATH<x>:SPECTral:LOCk?
Arguments
ON turns on the parameter lock for the specified math waveform.
OFF turns off the parameter lock for the specified math waveform.
<NR1> = 0 disables the parameter lock for the specified math waveform; any
other value enables the parameter lock.
Examples
MATH1:SPECTRAL:LOCK ON turns on the parameter lock for Math 1, which
causes the parameters for Math 1 and Math 2 waveforms to be locked together.
MATH1:SPECTRAL:LOCK? might return :MATH1:SP ECTRAL:LOCK 0, indicating
that the parameter lock for Math 1 waveform is turned off.
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-353
