Command Groups
Command
Description
HIStogram:SOUrce Sets or returns which source waveform will
be compared against the histogram box
when the histo
gram testing is enabled
HIStogram:S
TATE
Sets or retur
ns whether histogram
calculations are enabled
Horizontal Command Group
Horizontal commands control the time bases of the instrument. You can set the
time per division (or time per point) of the main time base. You can use the
Horizontal commands to do the following:
Set the scale, horizontal position and reference, and units of the time base
Get the screen resolution, time of first point and time of last point, or get all
the horizontal settings
Enable or disable the display of the time base
You may substitute SECdiv for SCAle in th e horizontal commands. This provides
program compatibility with earlier models of Tektronix instruments.
Command
Description
HORizontal? Returns all learnable settings for the
horizontal commands
HORizontal:ACQDURATION?
Returns the time base duration
HORizontal:ACQLENGTH?
Returns the record length
HORizontal:DIVisions? Returns the number of graticule divisions
over which the waveform is displayed
HORizontal:FAS Tframe? Returns all settings for the horizontal
FastFrame commands
HORizontal:FAS Tframe:COUNt Sets or returns the FastFrame frame c ount
Sets or returns the horizontal record length
to the number of sample points in each frame
HORizontal:FAS Tframe:MAX FRames? Returns the maximum number of FastFrame
frames which can be acquired at the current
frame length
HORizontal:FAS Tframe:MULtipleframes:
FRAMESTart:<wfm>
Sets or returns the start frame number on the
specified wav eform for FastFrame multiple
frames
HORizontal:FAS Tframe:MULtipleframes:
MODe
Sets or returns the mode for FastFrame
multiple frames
HORizontal:FAS Tframe:MULtipleframes:
NUMFRames:<wfm>
Sets or returns the number of frames on the
specified wav eform for FastFrame multiple
frames
2-24 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
