Command Groups
Command
Description
MEASUrement:IMMed:SO Urce<x> Sets or returns the source to measure “to”
or “from” for phase or delay immediate
measurements
MEASUrement
:IMMed:SOUrce<x>:SIGType
Sets or retur
ns the type of input signal used
for the specified measurement s ource
MEASUrement:IMMed:TYPe Sets or returns the type of the immediate
measurement
MEASUrement:IMMed:UN Its? Returns the units of the immediate
measureme
nt
MEASUrem
ent:IMMed:VALue?
Returns t
he value of the immediate
measurement
MEASUrement:MEAS<x>? Returns all measurement parameters for the
displayed measurement
MEASUrement:MEAS<x>:COUNt? Returns the number of values accumulated
since th
e last statistical reset
MEASUr
ement:MEAS<x>:DELay?
Returns the delay measurement parameters
for spe
cified measurement
MEASU
rement:MEAS<x>:DELay:DIREction
Sets o
r returns the search direction to use
for delay measurements
MEASUrement:MEAS<x>:DELay:EDGE<x> Sets or returns the slope of the edge
to use for delay “from” or “to” waveform
meas
urements
MEAS
Urement:MEAS<x>:MAXimum?
Retu
rns the maximum v alue found since the
last statistical reset
MEASUrement:MEAS<x>:MEAN?
Ret
urns the mean value accumulated since
the last statistical res et
MEASUrement:MEAS<x>:METHod Sets or returns the m ethod used to calculate
the 0% and 100% reference level
MEASUrement:MEAS<x>:MINImum ? Returns the minimum value found since the
l
ast statistical reset
M
EASUrement:MEAS<x>:NOISe
S
ets or returns the location of the noise
measurement on the eye waveform for
MEAS<x>
MEASUrement:MEAS<x>:REFLevel? Returns the reference levels
MEASUrement:MEAS<x>:REFLevel:
ABSolute:HIGH
Sets or returns the top level for rise time
(90% level)
MEASUrement:MEAS<x>:REFLevel:
ABSolute:LOW
Sets o r returns the low level for rise time
(10%)
MEASUrement:MEAS<x>:REFLevel:
ABSolute:MID<x>
Sets or returns the mid1 or m id2 level for
measurements
MEASUrement:MEAS<x>:REFLevel:
METHod
Sets or returns the reference level units used
for measurement calculations
MEASUrement:MEAS<x>:REFLevel:
PERCent:HIGH
Sets or returns the top level for rise time
(90% level)
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-41
