Hydro:Evolved User Manual
Page 104 © 2022 Smartrise Engineering, Inc. All Rights Reserved October 2022
12.3 Security Setting
Security must be set to ON per opening to lock out the floor. The front security marks the
landings with front openings that are secured and are located under address 32-0008 - 32-0010.
The rear opening mask marks the landings with rear openings that are secured and are located
under addresses 32-0012 – 32-0014. For the list of parameters, see the Hydro:Evolved
Parameter List.
NOTE: The security input must be assigned prior to setting up which floors require security access. See
section 19 Error! Bookmark not defined..
The following procedure describes how to setup security for front or rear car calls.
Navigate to MAIN MENU | SETUP | FLOORS. See Figure 55.
From the FLOORS menu, scroll and select, Security (Front or Rear).
Figure 125: FLOORS Menu – Security (Front or Rear)
From the SECURITY FLOORS menu, scroll and select the floors the front or rear door is
going to open. Setting the floor to On will enable security for the floor.
Figure 126: SECURITY FLOORS Menu
Scroll right and press Save.
12.4 Access Code
The access code is a feature that when a car call is pressed, its corresponding lamp begins
flashing, and the user has a set amount of time to enter a 4-digit code, one digit at time. Access
codes are only available for the first eight floors the car serves. The system compares the user
input sequence with the code stored in the parameter. If the car call button (CCB) sequence is
correct, the car call latches. If the code does not match or the time to enter the code has
elapsed, the lamp stops flashing and the user has to start from the beginning by pressing the
car call button and entering the correct sequence code. Access code security is bypassed when
the car is on Fire or EMS.
NOTE: Debug car calls bypasses all car call security options.
