Hydro:Evolved User Manual

3.2 Faults and Alarms

Figure 32: Faults and Alarms Menus

The table below lists the Faults and Alarms menu structures.

Table 14: Faults and Alarms Menu Structures

Description

MAIN MENU

Faults

Allows the user to access Fault data

Alarms

Allows the user to access Alarm data

Faults

Active

Displays current active faults that are preventing the car from

running

Logged

Displays the 32 latest faults stored in the systems non-volatile

memory with the most recent faults at the top

Clear Log

Clears the fault log history

Alarms

Active

Displays current active alarms

Logged

Displays the 32 latest faults stored in the systems non-volatile

memory with the most recent faults at the top

Clear Log

Clears the alarm log history

Status

Faults

Alarms

Setup

Debug

About

MAIN MENU

Active

Logged

Clear Log

Active

Logged

Clear Log
