Hydro:Evolved User Manual
Page 200 © 2022 Smartrise Engineering, Inc. All Rights Reserved October 2022
20.4 Types of Outputs
The tables below list the definitions for the types of outputs per category.
Table 40: Description of Auto Operation Outputs
Activates when the car is in the acceleration stage of its run.
Discrete arrival lantern output, set 1.
Discrete arrival lantern output, set 2.
Discrete arrival lantern output, set 3.
Discrete arrival lantern output, set 4.
Discrete arrival lantern output, set 5.
Discrete arrival lantern output, set 1.
Discrete arrival lantern output, set 2.
Discrete arrival lantern output, set 3.
Discrete arrival lantern output, set 4.
Discrete arrival lantern output, set 5.
Triggers an audible in car buzzer when the car is overloaded, on
fire, nudging, on EMS Phase 1, or when on Attendant and there is
a demand.
Activates if the car has finished its recall.
Activates when a car call is placed. This is used in Canada for blind
people.
Activates when the car is in an automatic mode of operation and
the passing chime disable Output is inactive. The chime is
triggered for 500ms every time the car's PI changes.
Activates when the car is in the deceleration stage of its run.
At a central control console, a distress and light buzzer will be
provided for each elevator and an acknowledge button common
to all elevators. Pressing the distress alarm button, triggering the
emergency stop switch, if a dispatched car remains at a landing
for >30 seconds, or if the electrical safety circuit is open will turn
on the distress light, and pulse the distress buzzer. The Distress
light will remain lit until the acknowledge button is pressed.
At a central control console, a distress and light buzzer will be
provided for each elevator and an acknowledge button common
to all elevators. Pressing the distress alarm button, triggering the
emergency stop switch, if a dispatched car remains at a landing
for >30 seconds, or if the electrical safety circuit is open will turn
on the distress light, and pulse the distress buzzer. The Distress
light will remain lit until the acknowledge button is pressed.
Switches power to a redundant set of Riser boards.
Activates if hall calls are not disabled and the car is not faulted.
Activates when the car is not in normal operation, is in motion, or
has its doors open.
