Hydro:Evolved User Manual
October 2022 © 2022 Smartrise Engineering, Inc. All Rights Reserved Page 47
The table below lists the Setup – Fire and Earthquake menu structures.
Table 18: Setup – Fire and Earthquake Menu Structures
Fire operation setup menu
Earthquake operation setup menu
Sets the main recall floor
Sets the designated alternate recall floor
Machine room smoke options
Key to recall to service floor
Secondary machine room smoke
Sets the main fire recall floor This value is zero based, so
the bottom most floor is zero
Sets the main recall opening as front or rear
Sets the alternate fire recall floor This value is zero
based, so the bottom most floor is zero
Sets the main recall opening as front or rear
Sets whether the elevator will recall to the main or
alternate landing when the main smoke is active
Flash fire hat when main smoke is active
Activates fire shunt output during Phase 1 recall if
triggered by main smoke input
Sets whether the elevator will recall to the main or
alternate landing when the alternate smoke is active
Flash fire hat when alternate smoke is active
Activates fire shunt output during Phase 1 recall if
triggered by alternate smoke input
Sets whether the elevator will recall to the main or
alternate landing when the hoistway smoke is active
Flash fire hat when hoistway smoke is active
