Hydro:Evolved User Manual
October 2022 © 2022 Smartrise Engineering, Inc. All Rights Reserved Page 143
15.2 Hall Mask Status
Hall Mask Status displays the status of front, rear, and latchable hall calls.
The following procedure describes how to view the hall call mask status.
Navigate to MAIN MENU | DEBUG | CAR DATA. See Figure 65.
From the Car Data Overview (see Figure 242), press the right button .
View the Hall Mask Status.
Figure 243: Hall Mask Status
The table below lists the Hall Mask Status definitions.
Table 27: Hall Mask Status Definitions
