Smartrise HYDRO:EVOLVED User Manual

Hydro:Evolved User Manual
Page 286 © 2022 Smartrise Engineering, Inc. All Rights Reserved October 2022
Fault Number
Fault Name
Description
6
PF GSWF
Preflight failed for the CT 501 (Gate switch
front) input.
7
PF GSWR
Preflight failed for the CT 502 (Gate switch
rear) input.
8
PF DZF
Preflight failed for the CT 503 (Door zone
front) input.
9
PF DZR
Preflight failed for the CT 504 (Door zone
rear) input.
COP Board
1
STARTUP
COP processor has reset.
2
PF HA INSP
Preflight failed for the COP-SF1 (Hoistway
access inspection) input.
3
PF IC ST
Preflight failed for the COP-SF2 (IC Stop
switch) input.
4
PF FSS
Preflight failed for the COP-SF3 (Fire Stop
switch) input.
5
PF IC INSP
Preflight failed for the COP-SF4 (IC
inspection) input.
The table below lists CPLD preflight status.
Table 52: CPLD Preflight Status
Number
Name
Description
0
INACTIVE
Preflight not in progress.
1
ACTIVE
Preflight check is in progress.
2
PASS
Preflight has completed and detected no
errors.
3
FAIL
Preflight has completed and detected
errors.
The table below lists CPLD preflight command.
Table 53: CPLD Preflight Command
Number
Name
Description
0
INACTIVE
No commands issued the EB relays.
4
PICK BYP
CPLD issuing override command to pick
the EB4 relay.
5
DROP RG
CPLD issuing override command to drop
the EB2 relay.
6
PICK RG
CPLD issuing override command to pick
the EB2 relay.
7
DROP BYP
CPLD issuing override command to drop
the EB4 relay.
