Activates when the car has completed EMS, Fire, or emergency
power recall.
Activates when the car is in attendant operation and there is a
hall call at a floor above.
Activates when the car is in attendant operation and there is a
hall call at a floor below.
Activates when the car is in EMS Phase 1 or Phase 2.
Activates when the car is in independent service operation.
Triggers when the car is in normal operation and is parked.
Activates when the car is in Sabbath operation.
Activates when the car is in an automatic mode of operation and
the load weigher has flagged an overloaded state.
Triggers when the car is moving down.
Triggers when the car is moving up.
Table 41: Description of Car Call (Front and Rear) Outputs
Table 42: Description of Controller Outputs
Lamp output when auto rescue is active.
Output signaling car is on battery power.
Activates when the primary brake pick switch signals the brake is
open.
Activates when the secondary brake pick switch signals the brake
is open.
AC primary brake pick output.
AC secondary brake pick output.
CEDES Maintenance Fan output. Blows air at Cedes tape when in
motion to clear accumulated dust.
Output to the Delta relay which picks the Run Contactor in a Wye
Delta starter configuration.
Triggers prerun energizing of the DSD DC drive.
Turns on car light and fan hardware.
Fan output that will remain active for an adjustable period of time
after each run.
Enables recommended travel direction of Magnetek drives.
