Hydro:Evolved User Manual
October 2022 © 2022 Smartrise Engineering, Inc. All Rights Reserved Page 159
Scroll right and press Save.
16.7 Hall Security Status
The Hall Security status displays the status of the hall call security hall boards.
The following procedure describes how to view the Hall Security status.
Navigate to MAIN MENU | STATUS | HALL SECURITY STATUS. See Figure 47.
From the Hall Security menu, scroll up or down to view the floors that are set for hall
security. See Figure 259.
16.8 Hall Call Masks
Hall call mask must be set to enable regular hall calls for a car. The hall call mask setting is
located under address 08-0209 – 08-0212. The value for the address varies depending on the
Function IDs of the Hall board installed. For the list of parameters, see the Hydro:Evolved
Parameter List.
The following procedure describes how to set hall call mask.
Navigate to MAIN MENU | SETUP | GROUP SETUP. See Figure 58.
From the GROUP SETUP menu, scroll and select Hall Call Mask.
Figure 270: GROUP SETUP Menu – Hall Call Mask
From the HALL CALL MASK menu, scroll and select if the function is enabled.
Figure 271: HALL CALL MASK Menu
Scroll right and press Save.
