Hydro:Evolved User Manual
October 2022 © 2022 Smartrise Engineering, Inc. All Rights Reserved Page 199
Disables the car controls for the rear DOB. All operations are
controlled remotely via a remote control panel. Used during
prison operation.
Indicates that the manual hall doors for all the middle floors rear
openings are closed.
Car door photoeye input indicating that the rear door light curtain
is obstructed and doors are not permitted to close.
When detected, allows for the alternate photoeye to be used
simultaneous with the primary photoeye to increase the field of
view. Used with Peelle light curtain.
Indicates that the safety edge is obstructed and doors are not
permitted to close. For freight doors only.
Indicates that the manual hall doors for the top floor rear opening
are closed.
Table 38: Description of Inspection Inputs
Moves the car down when on landing inspection mode.
Moves the car up when on landing inspection mode.
Moves the car down when on pit inspection mode.
Moves the car up when on pit inspection mode.
Table 39: Description of Safety Inputs
Puts car on flood operation.
Analog load weigher signal indicating the weight is above the
configured threshold and the car cannot take additional
passengers, car will remove itself from group (stop taking hall
calls).
N/C input signals low oil.
N/C input signals low pressure.
N/C input signals motor overheat.
Analog load weigher signal indicating the weight is above the
configured threshold and the car cannot move. Car will remain
stopped with an overload fault.
Indicates if in car emergency phone has failed.
Resets the emergency phone failure buzzer.
N/C input signals cold oil.
