Hydro:Evolved User Manual
Page 180 © 2022 Smartrise Engineering, Inc. All Rights Reserved October 2022
Figure 320: HYDRO SETUP Menu – Hydro Speed Setup
From the Up Distance or Down Distance menu, select the time for which the car is
expected to transition from high speed to low speed.
Figure 321: Up Distance Menu
Figure 322: Down Distance Menu
Scroll back to GENERATE THRESHOLDS AND DISTANCES and select YES. If YES is not
selected, new thresholds and slowdowns are not generated.
Figure 323: GENERATE THRESHOLDS AND SLOWDOWNS? Menu
Selecting yes will generate the values for slowdown distance up, slow down distance
down, and threshold.
a. if overshooting occurs, following instructions on for Car Overshooting and repeat
step 1-4.
b. If leveling time is too long or short, follow instructions for Adjust Leveling Time
and repeat step 1 - 4.
18.4.7.1 Car Overshooting
Overshooting is where the car goes beyond floor level. To prevent overshooting, increase the
time. This causes the car to slow down sooner which increases the slowdown distance.
The following procedure describes how to resolve car steady state if overshooting occurs:
