Hydro:Evolved User Manual
October 2022 © 2022 Smartrise Engineering, Inc. All Rights Reserved Page 171
18.3.3.5 Over Temperature
When an over temperature condition occurs in the secondary soft starter, the soft starter goes
into recovery mode. This will in turn shut down the motor to prevent internal damage to the
motor.
The following procedure describes how to set the over temperature limit.
Navigate to MAIN MENU | SETUP | HYDRO. See Figure 60.
From the HYDRO SETUP menu, scroll and select Soft Starter. See Figure 282.
From the SOFT STARTER menu, scroll and select Secondary. See Figure 294.
From the SECONDARY menu, scroll and select Over Temperature.
Figure 300: SECONDARY Menu – Over Temperature
From the OVERTEMPERATURE LIMIT menu, enter the maximum temperature. See
Figure 293.
Scroll right and press Save.
18.3.4 Run With One Soft Starter
When a particular job supports two soft starters, and this parameter is ON, the car will be
allowed to run even if one of the soft starter is faulted, only if the faults are not soft starter
specific. In this situation, soft starter faults will instead be asserted as alarms. This option is only
available if the secondary soft starter is enabled.
The following procedure describes how to run the elevator with one soft starter.
Navigate to MAIN MENU | SETUP | HYDRO. See Figure 60.
From the HYDRO SETUP menu, scroll and select Soft Starter. See Figure 282.
From the SOFT STARTER menu, scroll and select Run With One Soft Starter.
Figure 301: SOFT STARTER Menu – Run With One Soft Starter
