Hydro:Evolved User Manual
Page 240 © 2022 Smartrise Engineering, Inc. All Rights Reserved October 2022
30 Safety
Safety measures are taken to prevent personal injury and to protect the equipment.
30.1 Lock Clip
Lock clip time is the amount of time the controller disregards an open hall lock. This prevents
intermittent interlock faults.
The following is an example of setting up lock clip.
Navigate to MAIN MENU | SETUP | SAFETY. See Figure 33.
From the SAFETY menu, scroll and select Lock Clip.
Figure 442: SAFETY Menu – Lock Clip
From the LOCK CLIP menu, set the time of the lock.
Figure 443: LOCK CLIP Menu
Scroll right and press Save.
30.2 General ODL
The General overspeed debounce limit (ODL) sets the distance for miscellaneous limits.
The following is an example of setting up the general ODL.
Navigate to MAIN MENU | SETUP | SAFETY. See Figure 33.
From the SAFETY menu, scroll and select General ODL.
Figure 444: SAFETY Menu – General ODL
