Hydro:Evolved User Manual
Page 50 © 2022 Smartrise Engineering, Inc. All Rights Reserved October 2022
The table below lists the Setup – Miscellaneous menu structure.
Table 19: Setup – Miscellaneous Menu Structure
Miscellaneous menu options
Set Position Indicator labels
Set internal clock time for fault identification
Bypasses terminal limit faults. This option is
automatically turned off when in automatic operation.
Enable/Disable Construction Box. When enabled,
onboard inspection buttons are ignored on construction
operation and onboard inputs are used.
Sets the max run time allowed in automatic operation
before the car faults (F116). If set to zero, this fault is
suppressed.
Requires In-Car inspection to enable CT inspection
When set ON, CE travel arrows reflect the motion
direction of the car. When set OFF, the arrows reflect the
motion direction of the car and the arrival direction after
a run.
When set ON, car call security enable input latches a car
call
Sets the time the car may be idle before its fan and light
output is turned off. If a longer timer is needed, the
extended fan and light timer should be used instead.
Units are in seconds.
Extended fan and light timer
Sets the floor the car moves to when the car to lobby
input is activated. This value is zero based.
Sets the time before arriving at a floor to update arrival
lantern outputs. If set to zero, arrival outputs updates
when doors begin to open. Units are in seconds.
Car out of service options
Sets the time to delay car direction changes. Allows time
for passengers to enter their car calls. Units are in 1
second counts.
Parameter default options
