Hydro:Evolved User Manual
October 2022 © 2022 Smartrise Engineering, Inc. All Rights Reserved Page 169
From the SECONDARY menu, scroll and select Enable Secondary.
Figure 295: SECONDARY Menu – Enable Secondary
From the ENABLE SECONDARY SOFT STARTER menu, select ON to enable the secondary
soft starter.
Figure 296: ENABLE SECONDARY SOFT STARTER Menu
Scroll right and press Save.
18.3.3.2 Ramp Up Time
The ramp up time is the time it takes for the secondary soft starter to ramp up to full voltage,
that eventually increases the amount of current applied to the motor to reduce torque.
The following procedure describes how to set the soft starter ramp up time.
Navigate to MAIN MENU | SETUP | HYDRO. See Figure 60.
From the HYDRO SETUP menu, scroll and select Soft Starter. See Figure 282.
From the SOFT STARTER menu, scroll and select Secondary. See Figure 294.
From the SECONDARY menu, scroll and select Ramp Up Time.
Figure 297: SECONDARY Menu – Ramp Up Time
From the RAMP UP TIME menu, set the time for the soft starter to ramp up to full
voltage. See Figure 287.
Scroll right and press Save.
